Power 500W(RMS) 1000W(PEAK)
Frequency Response 55Hz-19KHz
Sensitivity 99dB/1W/1M
Nominal Impedance 8Ω
Technial Parameter
LF Unit: 1x15＂(75mm) Driver Unit
HF Unit: 1x34 mm Driver Unit
Power: 500W(RMS) 1000W(PEAK)
Frequency Response: 55Hz-19KHz (-3dB)
Sensitivity: 99dB/1W/1M
Max. SPL: 125dB(RMS) 131dB(PEAK)
Nominal Impedance: 8Ω
Cover Range: 90°× 60°(H×V)
Hanging Hardware: 12 x M8 screws hanging point
Handle: 2
Bracket fixed seat: 35mm base bracket hole
Connector: 2×NL4 Socket, +1, -1
Box Material: CNC manufacturing, high density fiberboard
Weight: 24.5Kg
Size: (W x D x H) 426x431x684mm
